20FT Double Door Shipping Container
Dual Access. Maximum Flexibility. Built for Transport or On-Site Use.
This 20FT Double Door Shipping Container is engineered for applications requiring efficient two-way access, organized loading, and ISO-compliant mobility. Built from CORTEN weathering steel and fitted with CSC and ISO corner castings, it’s suitable for intermodal shipping, secure field storage, or custom modification.
With reinforced container doors on both ends and an ergonomic high-handle locking system, this unit enables improved flow of goods, safer access points, and better compartmentalization. The symmetrical design makes it particularly useful in environments where time, access, and layout flexibility are mission-critical.
Technical Specifications
Specification | Metric Measurement |
---|---|
Internal Dimensions (L×W×H) | 5.844 × 2.352 × 2.393 m |
External Dimensions (L×W×H) | 6.058 × 2.438 × 2.591 m |
Door Opening (W×H) | 2.343 × 2.280 m (Front + Rear) |
Internal Volume | 32.90 m³ |
Tare Weight | 2,355 kg |
Max Payload | 28,125 kg |
Max Gross Weight | 30,480 kg |
Standard Color | RAL 5013 – Cobalt Blue |
Structural & Functional Features
-
Container Doors on Both Ends
Allows for separate loading zones, walk-through layouts, or staggered access points. -
CSC Plate Included
Pre-certified for international shipping and ISO stacking requirements. -
High-Handle Locking Gear
Easier leverage and ergonomic access, especially in frequent-use scenarios. -
Lockbox Protection
Built-in steel casing for padlock installation enhances site security. -
Ventilation System
Standard louvered vents maintain air circulation and minimize condensation. -
Marine-Grade Flooring
28mm thick, 19-ply hardwood plywood designed for heavy-duty loading and moisture resistance. -
Stackable Build
ISO corner castings on all 8 corners for crane-lift compatibility and container-to-container deployment.
Ideal Applications
Intermodal Transport
Container is CSC and ISO-certified, supporting global transit, stacking, and cross-docking protocols.
Construction & Field Operations
Organize tools, PPE, and bulk materials with separation between the front and rear compartments.
Warehouse & Distribution
Improves mid-aisle access, shortens pick-and-pack times, and enables split loads or staggered inventory flow.
Agriculture & Farming
Store feed at one end, machinery or chemicals at the other — minimizing cross-contamination and travel time.
Conversion Projects
Excellent foundation for modular pop-up stores, walk-through kiosks, mobile cafés, or event booths.
Certification & Compliance
This unit includes a valid CSC plate and complies with:
-
ISO 668 / ISO 1496 standards
-
CSC (International Convention for Safe Containers)
-
Safety and handling guidelines for road, rail, and sea movement
Documentation and inspection records are available upon request.
